Key Specifications & Features

Here is a breakdown of the main features and specification values:

Feature Specification / Description Input Voltage / Range AC 100‑240V, 50‑60 Hz (universal wide input) Lygte-info+3FixShop+3tvcmall+3 Total Output Power ~ 40 W (some listings claim higher, but measured tests suggest ~40 W) tvcmall+3Mobspares+3Lygte-info+3 Output Ports / Types 4 × standard USB ports, 1 × QC 3.0 port, 1 × USB‑C (Type‑C) port, and 1 wireless (Qi) charging pad on top Lygte-info+4FixShop+4tvcmall+4 USB Standard Ports Output 5 V, up to 2.4 A per port (depending on device demand) FixShop+3mobilechip+3FansCreate+3 QC 3.0 Port Output Multiple voltage levels: 5 V @ ~3.4 A, 9 V @ ~2.3 A, 12 V @ ~1.5 A (as per spec) Mobspares+3mobilechip+3FixShop+3 USB‑C Port Output 5 V up to 3 A (some variants) FixShop+2Mobspares+2 Wireless Qi Output 7.5 W to 10 W (depending on device) tvcmall+3mobilechip+3FixShop+3 Display LCD (or LED) real‑time display showing voltage/current per output. The display monitors the charging environment. FixShop+2Lygte-info+2 Material / Build ABS + PC (flame retardant, temperature resistant) FixShop+2tvcmall+2 Physical Size & Weight From teardown tests: ~ 115.5 × 80.0 × 42.0 mm, weight ~ 253 g (some listings differ) Lygte-info Idle Power Draw ~0.3 W when idle (no load) Lygte-info Protection & Smart Features Overload protection: if total draw exceeds rated output, the unit may disable or flicker display until load is removed. FansCreate+2Lygte-info+2
Smart current distribution / “intelligent shunting” (i.e. it adjusts output per device) tvcmall+3Mobspares+3FansCreate+3
Over‑current, over‑voltage protections likely embedded (common in such hubs) FixShop+1

Real‑World Performance & Limitations (Based on Teardown / Tests)

While manufacturer claims are useful, independent tests and teardown reviews give insights into actual behavior and limitations. Some of the observed behavior includes:

• The QC 3.0 port is realized via an internal boost converter from 5 V; when multiple ports are under heavy load, the QC port may not maintain its highest voltage/current output. Lygte-info

• The USB standard ports tend to share current; heavy loads may cause voltage drops or interference between outputs. Lygte-info

• The display does not always show actual voltages on non-QC ports — e.g. it may always show ~5.2 V even under varying loads. Lygte-info

• Under full load (e.g. trying to draw near 40 W across ports), the unit becomes warm (measured up to ~80 °C in some internal parts). Lygte-info

• The wireless (Qi) function is weaker and sometimes has difficulty maintaining consistent charging current under load. Lygte-info

• The overload protection seems to kick in around 8.5 A of total current across outputs (which is beyond spec) — when that happens, the unit may stop or flicker. Lygte-info

Overall, the unit performs decently under moderate loads, but pushing all ports near maximum simultaneously reveals limitations in real output stability, heat, and regulation.

Use Cases & Suitability

This kind of charger is best suited for the following scenarios:

• Charging multiple low- to moderate-power devices simultaneously (phones, tablets, cameras, wearables)

• Environments where a single consolidated charger is more convenient than multiple adapters

• Use cases where a somewhat lower priority on ultra-fast charging on all ports is acceptable

• For travel or shared workstations where many devices need charging

However, it may not be ideal if:

• You expect full 3A+ fast charging simultaneously on many devices

• You have devices that demand very tight voltage regulation

• Thermal dissipation is a concern (in hot climates)
